Siemens SINAMICS S120 Combi User Manual

S120 Combi Power Modules
3.5 Meaning of the LEDs on the S120 Combi
SINAMICS S120 Combi
82 Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
3.5 Meaning of the LEDs on the S120 Combi
The SINAMICS S120 Combi has two LEDs to display the status of the components. The
software assigns a priority to the status signals from the individual components. The most
important and/or most informative status is output for the complete S120 Combi.
The status is immediately output if any component develops a fault. The ready to run
indication is only issued if all of the components have signaled that they are ready to run.
The LED statuses for the S120 Combi are described in the table below. The status display
always refers to the complete S120 Combi.
Table 3- 16 Meaning of the LEDs on the S120 Combi
Status Description, cause Remedy
RDY DC LINK
Off Off Electronics power supply is missing or outside permissible
tolerance range.
Connect/test the electronics
power supply
Off The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
-
Orange The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is present.
-
Green
Red The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is too high.
Check the line supply
voltage.
Orange Orange DRIVE-CLiQ communication is being established. -
Red - This component has at least one fault.
Note:
The LED is activated regardless of whether the
corresponding messages have been reconfigured.
Remedy and acknowledge
fault
Green/Red
(0.5 Hz)
- Firmware is being downloaded.
Green/Red
(2 Hz)
- Firmware has been downloaded.
Wait for POWER ON.
Carry out a POWER ON
Green/Orange
or
Red/Orange
- Detection of the component via LED is activated (p0124)
Note
Both options depend on the LED state when activated via
p0124 = 1.
-
WARNING
Hazardous DC link voltages may be present at any time regardless of the state of the "DC
LINK" LED.
The warning information on the components must be carefully observed!
