Line-side power components
2.6 Line filters
SINAMICS S120 Combi
Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
37
2.6.3 Interface description
2.6.3.1 Overview
///
/RDGFRQQHFWLRQ
3URWHFWLYHFRQGXFWRU
/LQHFRQQHFWLRQ
3URWHFWLYHFRQGXFWRU
0RXQWLQJSRVLWLRQ
9HUWLFDO
Figure 2-4 Line filter for S120 Combi
Either the upper or lower PE screw can be used for the connection. One of the screws
remains unused. "Looping-through" the protective connection to the line reactor is not
permissible.
