3.1 Introduction
SINAMICS S120 Combi
Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
59
3.1.3 Approved controls
The S120 Combi is approved for operation with the following controls:
● SINUMERIK 828D with PPU versions
– PPU 24x.2
– PPU 26x.2
– PPU 28x.2
Table 3- 2 Overview of the order numbers of the approved SINUMERIK 828D controls
PPU version Keyboard Order number (without CNC software)
240.2 Vertical 6FC5370-4AT20-0AA0 (Turning)
6FC5370-4AM20-0AA0 (Milling)
241.2 Horizontal 6FC5370-3AT20-0AA0 (Turning)
6FC5370-3AM20-0AA0 (Milling)
260.2 Vertical 6FC5370-6AA20-0AA0
261.2 Horizontal 6FC5370-5AA20-0AA0
280.2 Vertical 6FC5370-8AA20-0AA0
281.2 Horizontal 6FC5370-7AA20-0AA0
3.1.4 Expansion axes that can be connected
The S120 Combi can be expanded with Motor Modules from the SINAMICS S120 Booksize
Compact series by one or two axes.
Table 3- 3 Expansion axes for the S120 Combi Power Modules
Motor Module Booksize Compact Width Order number
Single Motor Module 3 A 50 mm 6SL3420-1TE13-0AA0
Single Motor Module 5 A 50 mm 6SL3420-1TE15-0AA0
Single Motor Module 9 A 50 mm 6SL3420-1TE21-0AA0
Single Motor Module 18 A 75 mm 6SL3420-1TE21-8AA0
Double Motor Module 2 x 1.7 A 75 mm 6SL3420-2TE11-7AA0
Double Motor Module 2 x 3 A 75 mm 6SL3420-2TE13-0AA0
Double Motor Module 2 x 5 A 75 mm 6SL3420-2TE15-0AA0
NOTICE
Number of expansion axes
A maximum of two expansion axes can be connected to an S120 Combi Power Module, i.e.
two Single Motor Modules or one Double Motor Module.
For a description of the Motor Modules Booksize Compact, see Chapter "Motor Modules
Booksize Compact as expansion axes".
