Page #130 background imageLoading...
Page #130 background image
Motor Modules Booksize Compact as expansion axes
7.5 Meaning of the LEDs on the Motor Module Booksize Compact
SINAMICS S120 Combi
128 Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
7.5 Meaning of the LEDs on the Motor Module Booksize Compact
Table 7- 5 Meaning of the LEDs on the Single Motor Module/Double Motor Module
Status Description, cause Remedy
RDY DC LINK
OFF OFF Electronics power supply is missing or outside
permissible tolerance range.
–
-- The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
–
Orange The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is present.
–
Green
Red The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is too high.
Check the line supply
voltage.
Orange Orange DRIVE-CLiQ communication is being established. –
Red -- This component has at least one fault.
Note:
The LED is activated regardless of whether the
corresponding messages have been reconfigured.
Remedy and acknowledge
fault
Green / Red
(0.5 Hz)
-- Firmware is being downloaded. –
Green / Red
(2 Hz)
-- Firmware download is complete. Wait for POWER ON. Carry out a POWER ON
Green/Orange
or
Red/Orange
-- Detection of the components via LED is activated
(p0124).
Note:
Both options depend on the LED state when activated
via p0124 = 1.
–
DANGER
Hazardous DC link voltages may be present at any time regardless of the state of the "DC
LINK" LED.
The warning information on the component must be carefully observed!
