Siemens SINAMICS S120 Combi User Manual

Cabinet design and EMC
13.6 24 V DC supply
SINAMICS S120 Combi
Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
247
13.6.5 Selecting power supply units
You are advised to use the devices in the following table. These devices meet the applicable
requirements of EN 60204-1.
Table 13- 5 Recommended SITOP Power
Rated output
current [A]
Phases Rated input voltage [V]
Working voltage range [V]
Short-circuit current [A] Order number
5 1 / 2 120 - 230/230 - 500
85 - 264/176 - 550 AC
Approx. 5.5 (power up),
typ. 15 for 25 ms
(operation)
6EP1333-3BA00-8AC0
10 1 / 2 120 - 230/230 - 500
85 - 264/176 - 550 AC
Approx. 12 (power up),
typ. 30 for 25 ms
(operation)
6EP1334-3BA00-8AB0
1 / 2 120/230
85 - 132/176 - 264 AC
6EP1336-3BA00-8AA0 20
3 3-ph. 230/400 to 288/500
320 - 550 AC
Approx. 23 (power up),
typ. 60 for 25 ms
(operation)
6EP1436-3BA00-8AA0
1 / 2 120/230
85 - 132/176 - 264 AC
6EP1337-3BA00-8AA0 40
3 3-ph. 230/400 to 288/500
320 - 550 AC
Approx. 46 (power up),
typ. 120 for 25 ms
(operation)
6EP1437-3BA00-8AA0
Note
When using an external 24 V power supply with a continuous current > 20 A, an overcurrent
protection device must be used for the S120 Combi Power Module, the cables and the
busbars. A circuit breaker is recommended as overcurrent protection device.
The tripping characteristic of the circuit breaker depends on
• the loads to be protected and
• the maximum current provided by the power supply unit in the case of a short-circuit.
Table 13- 6 Recommendation for Control Supply Module
Rated output
current [A]
Phases Input voltage range [V] Short-circuit current [A] Order number
20 3 380 V AC -10% (-15% < 1 min)
to 480 V AC +10%
DC 300 – 800
< 24 6SL3100-1DE22-0AA1
See also catalog NC61.
WARNING
When an external power supply is used, e.g. SITOP, the ground potential must be
connected to the protective conductor system (DVC A).
