Additional system components
10.3 DRIVE-CLiQ Hub Module External DME20
SINAMICS S120 Combi
204 Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
10.3.7 Specifications for use with UL approval
Pre-assembled cables
Sensor/actuator cable, 5-pin, variable cable,
free cable end at straight socket M12-SPEEDCON,
cable length: 2, 5, 10, 15 m
SAC-5P-xxx-186/FS SCO
Up to 100 m on request
Phoenix Contact
Cables to be assembled by the user
Cable Connector
Cable coil, black PUR/PVC, 5-pin
Conductor colors: brown/white/blue/black/gray
Cable length: 100 m
SAC-5P-100.0-186/0.75
Order number: 1535590
Sensor/actuator connector, socket, straight, 5-pin, M12,
A-coded
Screw connection, metal knurl,
cable gland Pg9
SACC-M12FS-5CON-PG9-M
Order number: 1681486
Phoenix Contact
Power supply
The DME20 must be connected to a 24 V power supply with voltage limitation.
● SITOP 6EP1x.. or 6ES7307..
● SINAMICS Control Supply Module 6SL3100-1DE22-0Axx
Pin assignment of the cable
Table 10- 24 Connection to X524 electronics power supply
Pin Designation Technical specifications
1 (brown)
1)
Electronics power supply
2 (white)
1)
Electronics power supply
3 (black)
1)
Electronics ground
4 (blue)
1)
Electronics ground
5 (gray)
1)
Not connected internally
The connection voltage of 20.4 V – 28.8 V refers to
the (terminal) voltage at the DME20. This must be
taken into account when selecting the cable cross-
section and supply cable lengths.
Pins 1 and 2: jumpered internally
Pins 3 and 4: jumpered internally
1) The colors stated refer to the cable specified above
