Cabinet design and EMC
13.7 Connection system
SINAMICS S120 Combi
248 Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
13.7 Connection system
13.7.1 DRIVE-CLiQ signal cables
Note
Only MOTION-CONNECT 500 and MOTION-CONNECT 800PLUS DRIVE-CLiQ cables are
permitted for the connection. The maximum cable length for MOTION-CONNECT 500 cables
is 100 m, for MOTION-CONNECT 800PLUS cables 75 m.
The maximum permissible cable length for the use of DRIVE-CLiQ couplings is calculated as
follows:
ΣMC500 + 4/3 x ΣMC800PLUS + n
C
x 5 m ≤ 100 m
ΣMC500: Total length of all MC500 cable segments (fixed routing)
ΣMC800PLUS: Total length of all MC800PLUS cable segments (tow chain)
n
C
: Number of DRIVE-CLiQ connectors (max. 0...3)
