Siemens SINAMICS S120 Combi User Manual

Encoder system connection
11.2 Sensor Module External SME20
SINAMICS S120 Combi
220 Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
11.2.6 Technical data
Table 11- 8 Technical data
6SL3055-0AA00-5EA3 Unit Value
Electronics power supply
Voltage
Current (without encoder system)
Current (with encoder system)
Power loss
V
DC
A
DC
A
DC
W
24 DC (20.4 – 28.8)
≤ 0.15
≤ 0.25
≤ 4
Encoder system power supply
Voltage
Current
V
encoder
A
encoder
5 VDC
0.35
Encoder frequency that can be evaluated
(f
encoder
)
kHz ≤ 500
PE/ground connection On enclosure with M4/1.8 Nm screw
Weight kg 0.31
Degree of protection IP67
The maximum cable length at the encoder system interface depends on the current
consumption of the encoder system and the cross-section of the supply cores in the cable.
However, the maximum length is 10 m.
For encoder systems that operate in a supply voltage range from 4.75 V to 5.25 V, the
following diagram is obtained. The sample parameters shown are 0.28 mm² cross-section
(0.14 mm² supply cores plus 0.14 mm² Remote Sense cores) and 0.64 mm² (0.5 mm² supply
cores plus 0.14 mm² Remote Sense cores).
