S120 Combi Power Modules
3.9 Technical data
SINAMICS S120 Combi
Manual, Edition 07/2012, 6SL3097-4AV00-0BP3
95
4 axes Power Modules 6SL3111- 4VE21-6FA0 4VE21-6EA0 4VE22-0HA0
Circuit breaker (UL)
Type designation
Rated current:
Resulting rated
short-circuit current SCCR at 480 V
AC
A
kA
3VL2105-2KN30
50
65
3VL2105-2KN30
50
65
3VL2106-2KN30
60
65
Fuses (UL)
Type AJT Class J
4)
Rated current
Resulting rated
short-circuit current SCCR
at 480 V
AC
at 600 V
AC
A
kA
kA
AJT 35
35
65
200
AJT 35
35
65
200
AJT 60
60
65
200
Cooling method External air cooling
Cooling air requirement m
3
/h 160 160 160
Weight kg 18.9 18.95 19.05
1) The specified power ratings apply for the line supply voltage range from 380 V to 480 V
2) The external fan unit 6SL3161-0EP00-0AA0 has been taken into account for the specified losses - also refer to the
power loss calculation for partial load operation in Chapter "Control cabinet installation".
3) For an overview, see the power loss tables in the chapter titled "Control cabinet installation"
4) Source of supply: Ferraz Shawmut, http://de.ferrazshawmut.com
