13.7 Commissioning NX <-> Drive
CNC Part 1 (NCK, PLC, drive)
210 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
– In the next step, you enter the axis component number for the setpoint and actual
value.
– Under "Axis-MD" with "Axis+", you select the corresponding axis.
The following axis machine data must be adapted for each axis:
MD30110 CTRLOUT_MODULE_NR (setpoint channel)
MD30220 ENC_MODUL_NR (actual-value channel)
MD30130 CTRLOUT_TYPE (Type of output setpoint)
MD30240 ENC_TYPE (acquisition actual value),"1" for incremental encoder or "4" for
absolute value encoder.
Note
The commissioning engineer must ensure that the operationally ready signal of the
infeed is interconnected with the parameter p864 from each drive.
