Fundamentals
15.8 Axis data
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
295
Number Name of identifier Name / remarks Reference
30230 ENC_INPUT_NR[0] Actual value assignment: Position measuring
system 1
1 = G1_XIST encoder 1 position actual value 1
2 = G2_XIST encoder 1 position actual value 2
30230 ENC_INPUT_NR[1] Actual value assignment: Position measuring
system 2
1 = G1_XIST encoder 2 position actual value 1
2 = G2_XIST encoder 2 position actual value 2
30240 ENC_TYPE[0] Type of actual value recording
0 = Simulation
1 = Incremental encoder
4 = Absolute value encoder with EnDat interface
Interface signals
Table 15-11 Switchover of position measuring system: Interface signals
DB number Bit, byte Name Reference
Axis/spindle-specific Signals from PLC to axis/spindle
31, ... 1.5 Position measuring system 1
31, ... 1.6 Position measuring system 2
Literature
Function Manual Basic Functions;
Speeds, Setpoint/actual value systems, Control: Setpoint/actual-value system
Function Manual Basic Functions;
Diverse Interface Signals: Interface signals to axis/spindle
