2.4 Screen layout
2
©Siemens AG 2008 All rights reserved.
2-44 SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition
If the status shows this symbol
, operating input is required.
1 Stop: No NC Ready
2 Stop: Mode Group Ready
3 Stop: EMERGENCY STOP active
4 Stop: Alarm active with stop
5 Stop: M0/M1 active
6 Stop: Block ended in SBL mode
7 Stop: Cycle stop active
8 Wait: No read-in enable
9 Wait: No feed enable
12 Wait: No axis enable
17 Wait: Feedrate override > 0%
18 Stop: Error in NC block
19 Wait: For external NC blocks
22 Wait: No spindle enable
23 Wait: Axis feedrate value is 0
31 Stop: No channel ready
45 Stop: SERUPRO search has found search target and the
NCK has stopped. SERUPRO is the abbreviation for
“SEarchRUn by PROgram test”; it is a new type of
block search.
If the status shows this symbol
operation is generally not required.
10 Wait: Remaining dwell time __ Sec. for seconds or
Remaining dwell time __ rev. for revolutions
This can be parameterized via an OPI variable. 0 =
sec./1 = rev.
11 Wait: No aux. funct. ackn.
13 Wait: Exact stop not reached
14 Wait: For positioning axis
15 Wait: For spindle
16 Wait: For other channel
20 Wait: Due to SYNACT instruction
21 Wait: Block search active
