01/2008 Operator Components/Operating Sequences
2.4 Screen layout
2
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 2-45
24 Wait: For tool change acknowledgement
25 Wait: For gear stage change
26 Wait: For position control
27 Wait: For thread cut
29 Wait: For punching
30 Wait: For safe operation
32 Stop: Oscillation active
33 Stop: Axis replacement active (block change inhibited
because axis replacement in progress)
34 Wait: For axis container rotation
35 Wait: AXCT axis active as slave axis
36 Wait: AXCT axis active as master axis
37 Wait: AXCT axis changing to follow-up
38 Wait: AXCT internal status change in axis
This delay status may be attributable to the following
causes:
• Activation of position control
• Requesting of zero marker
• Reference point approach active
• Parameter block change active
• Measuring system change active
• Measurement on-the-fly active
• Closed-loop controller enable removed
• Status change, axis/spindle disable
39 Wait: AXCT axis drive disable
40 Wait: AXCT axis overlaid motion active
41 Wait: AXCT axis axis replacement active
42 Wait: AXCT axis interpolator active
43 Wait: WAIT_FOR_CC_ENABLE:
Waiting for compile cycle
44 Wait: On access to system variable
46 Stop: ESR triggered
47 Wait: Axis container rotation waiting for spindle stop
48 Wait: Axis container rotation waiting for synchronization of
MD data (New-Config)
