Permissible power supply parameters T
3
= Permissible ambient temperature
Gas hazardous area Zone 1 / Div. 1:
SITRANS TH100/200/300
with DVM LCD
Gas hazardous area Zone 1:
SITRANS TH320/420
with display
U
i
= 27 V
I
i
= 90 mA
P
i
= 610 mW
T85 °C: -40 °C ≤ T
3
≤ +63 °C - ∆T2D T4: -40 … +85 °C - ∆T2G
T5: -40 … +75 °C - ∆T2G
T6: -40 … +60 °C - ∆T2G
U
i
= 25.2 V
I
i
= 84 mA
P
i
= 530 mW
T85 °C: -40 °C ≤ T
3
≤ +63 °C - ∆T2D -
See also
Gas hazardous area: Ex i / IS / Ex nA/ec / NI (Page 133)
Dust hazardous area: Ex i / IS / Ex tb / DIP (Page 137)
Technical data
11.1 Rated conditions
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
132 Operating Instructions, 08/2020, A5E47810090-AA
