Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 165
Navigate to MAIN MENU | SETUP | HYDRO. See Figure 60.
From the HYDRO SETUP menu, scroll and select Soft Starer.
Figure 282: HYDRO SETUP Menu –Soft Starter
From the SOFT STARTER menu, scroll and select Enable SR Soft Starter.
Figure 283: SOFT STARTER Menu – Enable SR Soft Starter
From the ENABLE SR SOFT STARTER menu, select ON to enable the soft starter.
Figure 284: ENABLE SR SOFT STARTER Menu
Scroll right and press Save.
18.3.2 Primary
The primary soft starter must have the ramp up, over voltage, over current, over temperature
configured.
18.3.2.1 Ramp Up Time
The ramp up time is the time it takes for the primary soft starter to ramp up to full voltage that
eventually increases the amount of current applied to the motor to reduce torque.
The following procedure describes how to set the soft starter ramp up time.
Navigate to MAIN MENU | SETUP | HYDRO. See Figure 60.
From the HYDRO SETUP menu, scroll and select Soft Starter. See Figure 282.
