Hydro:Evolved User Manual
Page 32 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
The table below lists the Status – Inputs, Outputs, and Expansion Status menu structures.
Table 12: Status – Inputs, Outputs, and Expansion Status Menu Structures
Displays information about the current state of the controller
Shows the status of all programmed inputs to the MR board
Shows the status of all programmed outputs from the MR board
Shows the status of the Valve board
Shows the status of the secondary Valve board
Shows the status of the soft starter
Shows the status of the secondary soft starter
Shows communication status for a group of Expansion boards
Shows the status of the Riser board
Shows communication status for all Hall boards
Shows communication status for all Hall Lantern boards
Shows communication status for all Hall Security boards
Shows the status of inspection related inputs
Shows the status of the front locks
Shows the status of the rear door locks
Shows the status of all hoistway accesses
Shows the status of safety inputs
Shows the status of all active relays
Shows the status of the front door operator signals
Shows the status of the rear door operator signals
Shows the status inputs under auto operation category
Shows the status of fire/earthquake inputs
Shows the status E-Power inputs
Shows the status of various other inputs
Shows the status of the control inputs
Shows the status of safety conditions
Shows the outputs that are in auto operation
Shows the status of front door outputs
Shows the status of rear door outputs
Shows the status of fire/earthquake outputs
Shows the status of E-Power outputs
Shows the status of inspection outputs
Shows the status of control outputs
