Hydro:Evolved User Manual
Page 308 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
From the Enter Door Command menu, the user can assert a command to either close,
open, or nudge a door.
NOTE: The display shows an option for front and rear doors when configured for rear
doors. If there are only front doors, then the display does not show an option for the
type of door.
Figure 601: Enter Door Command Menu (Front and Rear Doors)
Figure 602: Enter Door Command Menu (Front Doors Only)
38.5 View Network Packet
The view network packet allows the user to view the raw data and receive counts of packets
sent between the MR, CT, and COP boards.
The following procedure describes how to view the network packet.
Navigate to MAIN MENU | DEBUG | VIEW NETWORK PACKET. See Figure 63.
View the Network Packet
Figure 603: Network Packet
38.6 View Group Packet
The view group packet page allows the user to view the raw data and receive counts of packets
sent between group cars via the GN ± network.
The following procedure describes how to view group packets.
Navigate to MAIN MENU | DEBUG | VIEW GROUP PACKET. See Figure 63.
