Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 195
Table 33: Description of Controller Inputs
When active, and the car is put on battery rescue operation, car
will recall to the landing requiring the least energy to reach. When
inactive, car will fault until the manual rescue procedure is
executed.
When active, car will assert a battery fault indicating that the
battery in the Battery Rescue device may need replacing.
Indicates a Battery Rescue device is active. This is used in
combination with Auto Rescue when a battery lowering or
emergency rescue device is active.
AC primary brake BPS input. Signals that the brake has fully
picked. Only checked if programmed.
AC secondary brake BPS input. Signals that the brake has fully
picked. Only checked if programmed.
Feedback input from the delta relay which picks the run contactor
in a Wye Delta starter configuration.
Monitors safety relay for cutting the down high valve's neutral
side. If the input is high, the valve's neutral side is disconnected.
Only checked if programmed.
When active, causes the output LIGHT FAN to also activate.
Generic fault that will stop the car.
Monitors safety relay for cutting the inspection valve's neutral
side. If the input is high, the valve's neutral side is disconnected.
Only checked if programmed.
Indication to the controller that a manual rescue is occurring.
Puts the car in out of service operation.
Line monitoring hardware has detected voltage lines are out of
phase or missing. Only checked if programmed.
When the car is on automatic battery rescue operation. For
Magnetek drives, this indicates to the car that the easiest
direction to move is down. When inactive, this indicates that the
easiest direction is up.
When the car is on automatic battery rescue operation. For
Magnetek drives, this indicates to the car that it has determined
the easiest direction for the car to move, indicated by REC TRV
DIR.
Primary soft starter signaling a generic fault. Only checked if
programmed.
Secondary soft starter signaling a generic fault. Only checked if
programmed.
Feedback input from the contactor starter overload relay. Used
for jobs with a contactor starter.
