Hydro:Evolved User Manual
Page 312 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
• Recall Finished – The car is stopped at the requested recall floor and its doors are in a
requested state.
The following procedure describes how to view the recall status.
Navigate to MAIN MENU | DEBUG | Module Statuses. See Figure 65.
From the MODULE STATUS menu, scroll and select Recall Status.
Figure 615: MODULE STATUS Menu – Recall Status
From the Recall Status menu, view the state of the recall status.
Figure 616: Recall Status Menu
38.9.5 Fire Status
The Fire Status displays if Fire Phase 1 and 2 are active.
The following procedure describes how to view the fire status.
Navigate to MAIN MENU | DEBUG | MODULE STATUS. See Figure 65.
From the MODULE STATUS menu, scroll and select Fire Status.
Figure 617: MODULE STATUS Menu – Fire Status
From the Fire Status menu, view if the fire operation is active.
Figure 618: Fire Status Menu
