Hydro:Evolved User Manual
Page 314 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
From the Floor Learn Status menu, view if the status of the car is learning or not.
Figure 622: Floor Learn Status Menu
38.10 Car Destination
The car destination displays the status of a car in the group.
The following procedure describes how to view the car destination status.
Navigate to MAIN MENU | DEBUG | CAR DESTINATIONS. See Figure 65.
From the DESTINATION menu, view the car destination information.
Figure 623: DESTINATION Menu
The Destination menu displays the following:
• Landing – The landing number of the car’s current destination. The bottom landing
appears as 1.
• Type – The destination assignment’s call type.
• CC – F: Car call at front opening
• CC – R: Car call at rear opening
• CC – B: Car call at both front and rear openings
• DIR UP – F: Hall call up or consecutive calls above at front opening
• DIR UP – R: Hall call up or consecutive calls above at rear opening
• DIR UP – B: Hall call up or consecutive calls above at both openings
• DIR DN – F: Hall call down or consecutive calls below at front opening
• DIR DN – R: Hall call down or consecutive calls below at rear opening
• DIR DN – B: Hall call down or consecutive calls below at both openings
• Mask – The hall call mask for the car’s current destination assignment based on the car’s
current hall destination mask front (HMF)/rear (HMR) fields. The hall call mask of the
calls are cleared when the car arrives at the destination floor. See section 16.11 Errors.
