Hydro:Evolved User Manual
Page 22 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
CAT5* – The CAT5 supplies power and two serial communication channels.
There are two sets of DIP switch settings for the SR3030 board. Bank A (upper) and Bank B
(lower). Each setting is configured for a different functionality.
The table below lists the functionality and configuration for the CT/COP board SR3030 Bank A
DIP switch settings.
Table 4: CT/COP Board SR3030 Bank A DIP Switch Setting Configuration
DIP Switch
Functionality
Description
DIP 1
CPU Stop Switch
Halts parameter updates and used
to reset fire and latched faults.
DIP 2
N/A
N/A
DIP 3
N/A
N/A
DIP 4
N/A
N/A
DIP 5
N/A
N/A
DIP 6
N/A
N/A
DIP 7
Pop-up Blocker
Disables the fault pop-up messages.
Faults can still be viewed in the
active and logged faults.
DIP 8
N/A
N/A
The table below lists the functionality configuration for the CT/COP board SR3030 Bank B DIP
switch settings.
Table 5: CT/COP Board SR3030 Bank B DIP Switch Setting Configuration
DIP Switch
Functionality
Description
DIP 1
COP (Not CT)
Must be turned on for COP
operation and off for CT operation.
DIP 2
Enable Rear Doors
Must be set if rear doors are
present.
DIP 3
Enable Landing Insp
Must be set when conducting
landing maintenance.
DIP 4
Enable Pit Insp
Must be set when conducting pit
maintenance.
DIP 5
N/A
N/A
DIP 6
N/A
N/A
DIP 7
N/A
N/A
DIP 8
N/A
N/A
