The table below lists the Setup – Door Setup menu structure.
Table 16: Setup – Door Setup Menu Structure
Configure door parameters
Allows for manually opening and closing the doors
through the UI
Time car doors remains open when answering car calls
Time car doors remain open when answering hall calls
Time car doors remain open when answering ADA calls
Time car doors remain open when responding to door
hold button requests
Time car doors remain open when answering lobby calls
Time limit for a door to complete an opening or closing
request before faulting
Time doors spend trying to close before transitioning to
nudging which ignores photoeye. If set to zero, nudging
is disabled.
Enable or disable rear doors
PreOpening Distance (.019”)
The distance from a floor to start preopening doors. If
zero, preopening is disabled.
Activates door close output while in motion
Activates door close output while the doors are in closed
state
Activates door open output while the doors are in open
state
When set ON, door outputs are suppressed when the CT
Stop switch is active
When set ON, door outputs are suppressed when on
hoistway access inspection
Doors remain open while the car is idle
Timer for jumper on Gate switch (F98/F107) and jumper
on lock (F99/F108) faults. This value is added to a
minimum timeout of 1.6 seconds.
When set ON, detects jumper on open DOL instead of
GSW
The number of door faults allowed within 1-hour
window before the car goes out of service. If the car
goes out of service, it will remain out of service until the
hour window elapses. If set to zero, this feature is
disabled.
