Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 261
From the MR SMOKE menu, scroll and select Main or Alt.
Figure 489: MR SMOKE Menu – Main or Alt
From the USE ALT FLOOR menu, scroll and select if the main or alternate floor is
configured for MR smoke. See Figure 474.
Scroll right and press Save.
31.3.6.2 Flash Fire Hat
If the fire flash hat been enabled during MR smoke, a fire hat symbol on the panel flashes when
smoke has been detected.
The following procedure describes how to enable the flash fire hat.
Navigate to MAIN MENU | SETUP | FIRE. See Figure 56.
From the FIRE SERVICE menu, scroll and select MR Smoke. See Figure 488.
From the MR SMOKE menu, scroll and select Flash Fire Hat.
Figure 490: MR SMOKE Menu – Flash Fire Hat
From the FLASH FIRE HAT menu, scroll and select ON. See Figure 476.
Scroll right and press Save.
31.3.6.3 Shunt Trip
A shunt output is designed to trip a breaker shutting off the main power to the controller in
case of a fire in the machine room.
The following procedure describes how to set up the parameters in case smoke is detected.
Navigate to MAIN MENU | SETUP | FIRE. See Figure 56.
From the FIRE SERVICE menu, scroll and select MR Smoke. See Figure 488.
