Hydro:Evolved User Manual
Page 168 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
From the SOFT STARTER menu, scroll and select Primary. See Figure 285.
From the PRIMARY menu, scroll and select Over Temperature.
Figure 292: PRIMARY Menu – Over Temperature
From the OVERTEMPERATURE LIMIT menu, enter the maximum temperature.
Figure 293: OVERTEMPERATURE LIMIT Menu
Scroll right and press Save.
18.3.3 Secondary
If a secondary soft starter is available, the soft starter must be configured.
18.3.3.1 Enable Secondary
When enabled, the secondary soft starter is used to when a dual motor is required to lift a car
with a high capacity load.
The following procedure describes how to enable the secondary soft starter.
Navigate to MAIN MENU | SETUP | HYDRO. See Figure 60.
From the HYDRO SETUP menu, scroll and select Soft Starter. See Figure 282.
From the SOFT STARTER meu, scroll and select Secondary.
Figure 294: SOFT STARTER Menu – Secondary
To Next Page
