Hydro:Evolved User Manual

From the ALLOWED DISTANCE BOTTOM menu, scroll and select the distance from the

car to the pit.

Figure 364: ALLOWED DISTANCE BOTTOM Menu

Scroll right and press Save.

Press the left button until the HOISTWAY ACCESS menu displays.

From the HOISTWAY ACCESS menu, scroll and select Bottom Floor.

Figure 365: HOISTWAY ACCESS – Bottom Floor

From the BOTTOM FLOOR menu, select the bottom floor just above the pit.

Figure 366: BOTTOM FLOOR Menu

Scroll right and press Save.

Press the left button until the HOISTWAY ACCESS menu displays.

From the HOISTWAY ACCESS menu, scroll and select Bottom Opening.

Figure 367: HOISTWAY ACCESS – Bottom Opening
