Hydro:Evolved User Manual
October 2022 © 2022 Smartrise Engineering, Inc. All Rights Reserved Page 265
From the ALT MACHINE ROOM menu, scroll and select Enable Alt. MR.
Figure 499: ALT MACHINE ROOM Menu – Enable Alt. MR
From the ENABLE ALT MR menu, scroll and select ON.
Figure 500: ENABLE ALT MR Menu
Scroll right and press Save.
31.3.9.2 Hoistway 2 Smoke
When a group of elevators have a split hoistway, the options for secondary hoistway smoke
needs to be enabled.
31.3.9.2.1 Main or Alternate
The following procedure describes how to select if the car goes to main or alternate landing
when the HW 2 smoke is triggered.
Navigate to MAIN MENU | SETUP | FIRE. See Figure 56.
From the FIRE SERVICE menu, scroll and select Alt. Machine Room. See Figure 498.
From the ALT MACHINE ROOM menu, scroll and select HW 2 Smoke.
Figure 501: ALT MACHINE ROOM Menu – HW 2 Smoke
From the HOISTWAY 2 SMOKE menu, scroll and select Main or Alt.
Figure 502: HOISTWAY 2 SMOKE Menu – Main or Alt
