Hydro:Evolved User Manual

29.3 Arrival Update Time

The arrival update time is the time set to update the lantern outputs prior to arriving at a floor.

The following procedure describes how to set the arrival update time.

Navigate to MAIN MENU | SETUP | MISCELLANEOUS. See Figure 57.

From the MISCELLANEOUS menu, scroll and select Arrival Update Time.

Figure 440: MISCELLANEOUS Menu – Arrival Update Time

From the ARRIVAL UPDATE TIME menu, set the time to update lantern outputs.

Figure 441: ARRIVAL UPDATE TIME Menu

Scroll right and press Save.
