Hydro:Evolved User Manual
Page 290 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
Figure 555: EMS STATUS Menu – No Cars Assigned
32.11 Virtual Inputs
Virtual inputs display the status of inputs virtually instead of the main screens on the MR, CT, or
COP boards.
32.11.1 Remote Commands
The remote commands are the commands and have parameters that have been sent remotely
to the controller. The remote commands display the status of commands that would be sent by
remote access.
32.11.1.1 Car Call Security
The car call security displays the Hall security mask set via remote monitoring. Each bit
represents a set of four floors. For example, if floors 1 and 4 are set for security access, then the
display shows 00000009. If just floor 1 was set for security access, then the displays shows
00000001. If no floors are set for security access, then the display shows 00000000.
The following procedure describes how to view the car call security status for front or rear
doors.
Navigate to MAIN MENU | STATUS | VIRTUAL INPUTS. See Figure 50.
From the REMOTE COMMANDS menu, scroll and select Car Call Security.
Figure 556: REMOTE COMMANDS Menu – Car Call Security
From the SECURE CAR CALLS menu, select either the front or rear car calls.
Figure 557: SECURE CAR CALLS Menu – Front or Rear
