Hydro:Evolved User Manual
Page 172 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
From RUN WITH ONE SOFT STARTER menu, select ON to run with only one soft starter.
Figure 302: Run With One Soft Starter Menu
Scroll right and press Save.
18.4 Slowdown
Several peripherals affect the acceleration rate, deceleration rate, and speed of the car in the
up or down direction which includes, the temperature and viscosity of the oil, and weight.
Once all faults and alarms have been resolved during Construction and Inspection Mode, place
the DZ magnet 2” above the floor level for the bottom floor and 2” below the floor level for the
top floor. This creates an extra precaution for the car not to hit the ring buffer while travelling
in up direction and car buffer when traveling in down direction to avoid any unexpected
scenarios.
For proper operation, the controller and valves must be configured so the car has the proper
acceleration and slowdown time.
For a better/faster performance, the acceleration time should be less than 1 second.
If the deceleration rate of the car is slow and the car hits the Terminal Stopping Distance
(TSRD), reduce the deceleration rate of the valve (transition rate from High valve to Leveling
valve).
