Hydro:Evolved User Manual
Page 42 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
When set ON during nudging, the NDG output is
suppressed and only the buzzer sounds.
The estimated time it takes the doors to go from fully
closed to fully open. This value is learned after
performing a run with preflight disabled (01-0064) and
the learn opening time bit is ON (01-0165). This can help
improve dwell time delays when preflight is on. If set to
zero, this option is disabled.
Sets the time the car doors must be seen as safe before
the car is allowed to start a run on automatic operation.
Time is set in 100 ms counts. If zero, defaults to 300 ms.
Enable or disable swing operation for each front door
landing
Enable or disable swing operation for each rear door
landing
Sets the timeout which accounts for the delay between
CAM activation and locks being made for manual doors.
The units are in 100 ms counts. If set to zero, value
defaults to 4 seconds.
When set to ON, the CAM output controls hall
interlocks. Otherwise, interlocks are controlled by the
door operator.
When set to ON, the door has a fixed hall CAM. The car
is allowed to start a run without hall locks (hall closed
contacts still required). The car is allowed to move up to
2 feet without locks before faulting.
Sets the timeout between GSW and locks. If value is
zero, timeout is set to 500 ms. The units are in seconds.
Sets the timeout between CAM being energized and
closed contacts being made. If value is zero, timeout is
set to 500 ms. The units are in seconds.
When set to ON, the rear door on bottom floor is
disabled
