Hydro:Evolved User Manual
October 2022 ©2022 Smartrise Engineering, Inc. All Rights Reserved Page 39
Assign inputs to the Expansion 9-16 boards
Assign inputs to the Expansion 17-24 boards
Assign inputs to the Expansion 25-32 boards
Assign inputs to the Expansion 33-40 boards
Assign outputs from the MR board
Assign outputs from the CT board
Assign outputs from the COP board
Assign outputs from the Riser board
Assign outputs from the Expansion 1-8 boards
Assign outputs from the Expansion 9-16 boards
Assign outputs from the Expansion 17-24 boards
Assign outputs from the Expansion 25-32 boards
Assign outputs from the Expansion 33-40 boards
The amount of time the controller disregards an open hall lock. This
prevents intermittent interlock faults and for safety reasons, this
timer should not exceed five seconds
General overspeed debounce limit
Inspection overspeed debounce limit
NTS overspeed debounce limit
Terminal Speed Reducing Device overspeed debounce limit
Timers used for motion start sequence
Timers used for motion stop sequence
Sets the delay between activating the MR SAFE output and activating
the primary start motor output when moving in the up direction.
Sets delay between activating the SAFE output and activating the
valve when moving in the down direction.
Sets delay between activating the primary start motor output and
activating the valve when moving in the up direction.
Sets delay between activating the secondary start motor output and
activating the valve when moving in the up direction.
Sets delay between activating the Delta output and activating the
valve outputs
Sets delay between how long the pump motor continues to run after
closing the Up valves
Sets delay between the time between deactivating the pump motor
and turning off the MR-SAFE output
