Hydro:Evolved User Manual
Page 54 © 2022 Smartrise Engineering, Inc. All Rights Reserved October 2022
Turn ON/OFF which hall board functions the car will treat
as a swing hall call. NOTE: Swing call mask cannot overlap
with Medical Mask or Hall Call Mask.
Turn ON/OFF which hall board functions the car will treat
as Emergency Medical Service call. NOTE: Medical Mask
cannot overlap with Swing call mask or Hall Call Mask.
Turn ON/OFF which hall board functions are for rear
opening. This acts as a modifier to the mask it overlaps
with.
First set of Hall board functions that are turned ON are
linked together. If 01 is ON and 02 is ON, a hall call on
function 1 would latch the lamp for function 2.
Second set of Hall board functions that are turned ON are
linked together. If 01 is ON and 02 is ON, a hall call on
function 1 would latch the lamp for function 2.
Third set of Hall board functions that are turned ON are
linked together. If 01 is ON and 02 is ON, a hall call on
function 1 would latch the lamp for function 2.
Fourth set of Hall board functions that are turned ON are
linked together. If 01 is ON and 02 is ON, a hall call on
function 1 would latch the lamp for function 2.
Used in conjunction with the flood switch input. If a flood
is detected, then this parameter tells the controller which
floors to avoid. If set to zero, the elevator can go to all
floors. If the flood switch is active and this parameter is
set to one, then the car is not allowed to go to the
bottom floor. If set to two, then elevator cannot go to
bottom two floors, etc.
Allows car to continue to run above the configured flood
sensor floor
Allows flood operation to take priority over fire operation
Allows activation of Medical Phase 2 even if the car was
never placed on Phase 1
Allows exiting of EMS Phase 2 at any floor. Jobs with full
hospital service should have this parameter turned ON.
Jobs with EMT service should have this parameter OFF.
When set ON, the activation of a smoke or Fire Phase 1
key causes a car that is currently on EMS Phase 1 to exit
medical service and go on Fire Phase 1 recall. When
turned OFF, the car remains on EMS Phase 1.
