Tilt-angle-dependent assistance systems
Mast tilt angle display
Knowing the actual tilt angle of the lift mast
makes it easier to place loads into stock and
remove loads from stock. If the truck is equip-
ped with the "mast tilt angle display" assis-
tance system, the lift mast tilt angle (1) is
shown on the display.
Tilt end stop damping
This assistance system ensures that the
movement to the end positions is smooth. This
protects the load against jerking movements.
Automatic mast vertical positioning
(variant)
CAUTION
Risk of damage to property due to the lift mast collid-
ing with racks or other objects!
– Before using the "automatic mast vertical position-
ing" assistance system, position the truck at a suf-
ficient distance from racks and other objects.
The "automatic mast vertical positioning" as-
sistance system can be used to set down the
goods so that the goods are exactly vertical,
e.g. paper rolls. This prevents damage when
setting down the load. "Automatic mast verti-
cal positioning" functions when tilting for-
wards. A further variant is available which also
functions when tilting backwards. The tilt cylin-
ders run into the end stops gently to prevent
hard vibrations and impacts. Oscillating mo-
tions of the truck are minimised, thus
1,6 t
2,71 m
7,0°
Operation
4
Tilt-angle-dependent assistance systems
162 56368011531 EN - 01/2021 - 05
