– See the section entitled "Calibrating the au-
tomatic mast vertical positioning".
Function checking of the automatic
mast vertical positioning function
(variant)
CAUTION
Risk of damage to property due to the lift mast collid-
ing with racks or other objects!
– Before using the "automatic mast vertical position-
ing" assistance system, position the truck at a suf-
ficient distance from racks and other objects.
– To check the function of the automatic mast
vertical positioning function, proceed as fol-
lows:
– Push the "automatic mast vertical position-
ing" softkey
.
The
symbol appears in the display.
– Tilt back the lift mast until it reaches the end
stop.
– Tilt the lift mast forwards.
The lift mast must stop in the vertical position.
The automatic mast vertical positioning can be
used.
– If the lift mast does not stop in the vertical
position, do not use the assistance system.
– In this case, contact your authorised service
centre.
Calibrating the automatic mast verti-
cal positioning
The automatic mast vertical positioning is cali-
brated using a wizard on the display-operating
unit.
Operation
4
Tilt-angle-dependent assistance systems
164 56368011531 EN - 01/2021 - 05
