Roadways
Dimensions of roadways and aisle
widths
The following dimensions and aisle width re-
quirements apply under the specified condi-
tions to ensure safe manoeuvring. In each
case, a check must be performed to determine
whether a larger aisle width is necessary, e.g.
in the case of deviating load dimensions, at-
tachments, lift masts and tow couplings.
Within the EU, "Council Directive 89/654/EEC
concerning the minimum safety and health re-
quirements for the workplace" must be ob-
served. The respective national guidelines ap-
ply for areas outside the EU.
The required aisle widths depend on the di-
mensions of the load.
Required aisle widths with pallet
Model Type
Aisle width [mm]
With pallet
1000x1200
crosswise
With pallet
800x1200
lengthwise
RX20-14C 6219 3186 3311
RX20-16C 6220 3186 3311
RX20-16 6221 3269 3394
RX20-16L 6222 3377 3502
RX20-18 6223 3269 3394
RX20-18L 6224 3377 3502
RX20-20L 6225 3390 3516
RX20-16P 6226 3362 3487
RX20-16PL 6227 3470 3595
RX20-18P 6228 3362 3487
RX20-18PL 6229 3470 3595
RX20-20P 6230 3375 3501
RX20-20PL 6231 3483 3609
The truck must be used only on roadways that
do not have excessively sharp curves, exces-
sively steep gradients or excessively narrow
or low entrances.
Operation
4
Driving
