Tilting the lift mast
To tilt the lift mast forwards:
– Move the "tilting" operating lever (1) in the
direction of the arrow (C).
To tilt the lift mast backwards:
– Move the "tilting" operating lever (1) in the
direction of the arrow (D).
Movements of the lifting system and
meanings of the pictograms
A Lowering
B
Lifting
C
Tilting forwards
D
Tilting backwards
Controlling the lifting system using
the Joystick 4Plus
DANGER
Reaching into or climbing between moving parts of
the truck (e.g. lift mast, sideshifts, working equip-
ment, load carrying devices etc.) can lead to seri-
ous injury or death and is therefore prohibited.
– Observe the safety regulations for handling loads.
– Operate the lifting system from the driver's seat
only.
WARNING
Risk of accident as a result of an operating error!
These operating instructions describe how to operate
the lifting system in the factory configuration.
If the authorised service centre has configured a dif-
ferent configuration, the newly applied pictograms
must be observed to ensure safe operation. The op-
erating company must make all drivers aware of the
fact that a different configuration has been config-
ured.
– Observe the pictograms on the operating levers.
– Before use, check that the hydraulic functions are
working correctly.
The lifting, lowering and tilting movements of
the lift mast are controlled using the Joy-
stick 4Plus (1). The adhesive labels bearing
Operation
4
Lifting
242 56368011531 EN - 01/2021 - 05
