Fingertip
●
Joystick 4Plus
For clarity, the movements of the lifting system
are referred to by the letters (A, B, C, D) in this
subchapter.
A Lower the fork carriage
B Lift the fork carriage
C Tilting the lift mast forwards
D Tilting the lift mast backwards
– See the relevant sections in this subchap-
ter.
WARNING
Risk of injury due to delayed response from the
truck!
If the lifting movements are configured to use low dy-
namics, the lifting system responds after a delay
when the operating device is released, even in an
emergency. The fork carriage does not stop immedi-
ately upon release. It only stops after approximately
one second. This behaviour may also occur when
specific settings are configured for the Dynamic Load
Control 1 & 2 assistance systems.
– Work with particular attention and care.
DC
B
A
Operation
4
Lifting
232 56368011531 EN - 01/2021 - 05
