– Move the "lifting/lowering" operating lev-
er (3) in the direction of the arrow (A).
Tilting the lift mast
To tilt the lift mast forwards:
– Move the "lift mast" operating lever (4) in
the direction of the arrow (C).
To tilt the lift mast backwards:
– Move the "lift mast" operating lever (4) in
the direction of the arrow (D).
Movements of the lifting system and
meanings of the pictograms
A Lowering
B
Lifting
C
Tilting forwards
D
Tilting backwards
Operation
4
Lifting
240 56368011531 EN - 01/2021 - 05
