Picto-
gram
Attachment function
Adjust fork arms: open
Adjust fork arms: close
Rotate to the left
Rotate to the right
NOTE
The pictograms are affixed according to the
attachment fitted at the factory. If an attach-
ment with different functions is fitted, the au-
thorised service centre must check that the
pictograms bear the correct representation
and must change them if necessary.
Operation
4
Attachments
32756368011531 EN - 01/2021 - 05
