Handle
Parking brake lever
Steering wheel
Emergency off switch
Key switch or pushbutton
Compartment
Display/control unit "STILL Easy Control"
Operating devices for hydraulic and driving
functions
Compartment for storing the operating in-
structions and the hexagon socket wrench
for emergency lowering
1
2
3
4
5
6
7
8
9
Battery isolating switch
Driver's seat
Accelerator pedal
Brake pedal
Bottom plate
Pneumatic signal horn
Steering column adjustment lever
Reset button
Explosion-protection warning lights
10
11
12
13
14
15
16
17
18
On category 2 explosion-protected trucks, the
plastic parts are coated with a special antistat-
ic paint that prevents the build-up of an elec-
trostatic charge. The coated areas are identi-
fied with the decal information "ELECTRICAL-
LY CONDUCTIVE".
NOTE
The truck equipment may differ from the
equipment shown.
Overviews
3
Driver's compartment
