It is used as an operating device for the usual
functions of the truck, such as controlling light-
ing and windscreen wiper functions and
adjusting the driving dynamics.
It also shows information about the status of
the truck, such as the battery charge level,
display messages and operating hours.
The displays shown in this figure are exam-
ples. The display-operating unit provides fur-
ther display options that can be configured by
the driver or fleet manager.
– For information about the other display op-
tions, see the original operating instructions
entitled "STILL Easy Control display-operat-
ing unit".
The display-operating unit is attached to the
armrest, except in trucks equipped with multi-
lever operation. If the truck is equipped with
multi-lever operation, the display-operating
unit is swivel-mounted on the right A-pillar.
– For information on swivelling the display-op-
erating unit, see the section entitled "Adjust-
ing the swivelling display-operating unit" in
the chapter entitled "Checks and tasks be-
fore daily use".
NOTE
Do not put a label over the brightness sen-
sor (21) or cover it with anything. This sensor
allows the display to adapt to the current light
conditions.
