Operating & Maintaining the Objet1000 Plus 3D Printer
6–30 DOC-06810 Rev. A
6. Beforereturningtherollerwastecollectortotheprintblock,makesure
thatthepinsareclean.
Figure 6-34: Roller waste collector pins
To re-assemble the components:
1. Returntherollerwastecollectortotheprintblockandscrewonthe
covering(seefigure 6‐32onpage 29).
2. Loosenthescrewssecuringthesuctiontube.
Figure 6-35: Suction tube correctly positioned
3. Loweritsothattheholeinthepanelbehindthesuctiontubeisvisible,
andtightenthescrewstosecurethetube.
4. Attachtheright‐UV‐lampassemblytotheprintblockandreconnect
theUVpowerandfancables.
Roller waste
collector pins
Securing screws
