DOC-06810 Rev. A 6–61
Objet1000 Plus User Guide
12. Insertthetubeholderintothepumpassembly,makingsurethatthe
sidewiththeclampisonthesideofthepumpmarkedSUCTION.
Figure 6-96: Tube clamp on SUCTION side of pump
13. Closethetubelatch.
14. FromtheOptionsmenu,select
Maintenance Counters.
15. ScrolltoDirtPumpsTubesandclick
Reset.
Figure 6-97: Maintenance Counters screen
Tube clamp
Suction side
