13 X20 Brush lift (Brush lowering motor) 1 B_ABS (+)
13 X20 Brush lift (Brush lowering motor) 2 B_ABS (-)
14 X21 Squeegee lift (Squeegee lowering motor) 1 S_ABS (+), (Offset TASKI swingo 2100µicro)
14 X21 Squeegee lift (Squeegee lowering motor) 2 S_ABS (-), (Offset TASKI swingo 2100µicro)
15 X22 Reserve 1 TASKI IntelliTrail (+)
15 X22 Reserve 2 TASKI IntelliTrail (-)
16 X23 Drain pump 1 SWP (+), (TASKI swingo 4000/5000) Option /
(TASKI AERO 3500µirco => Reversing light
white)
16 X23 Drain pump 2 SWP (-), (TASKI swingo 4000/5000) Option /
(TASKI AERO 3500µirco => Reversing light
white)
17 X24 Flash (Warning light) 1 WL (+)
17 X24 Flash (Warning light) 2 WL (-)
18 X25 Lamp (Front light) 1 SW (+)
18 X25 Lamp (Front light) 2 SW (-)
19 X26 Pump 1 1 FWP_1 (+), (TASKI AERO 3500µicro => Not
connected)
19 X26 Pump 1 2 FWP_1 (-), (TASKI AERO 3500µicro => Not
connected)
20 X27 Pump 2 1 FWP_2 (+), (TASKI swingo 4000/5000 and
TASKI AERO 3500µicro => Not connected)
20 X27 Pump 2 2 FWP_2 (-), (TASKI swingo 4000/5000 and
TASKI AERO 3500µicro => Not connected)
Pos. Plug Description [plug] Pin Description [pin]
Table 2: Electronics connections
