GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-16
Copyright © 2020, Diversey
06.18.30 electronics - connections - 2100µicro_4000_5000_3500µicro_V2.00.fm
21 X28 Actors (Horn) 1 HUPE (+)
21 X28 Actors (Buzzer) 2 BUZZER (+)
21 X28 Actors (Magnetic valve) 3 DV (+)
21 X28 Actors (Brake) 4 FSB (+)
21 X28 Actors (Horn) 5 HUPE (-)
21 X28 Actors (Buzzer) 6 BUZZER (-)
21 X28 Actors (Magnetic valve) 7 DV (-)
21 X28 Actors (Brake) 8 FSB (-)
22 X30 Relay (Main relay) 1 MainRel (+)
22 X30 Relay (Seat switch) 2 Seat (+)
22 X30 Relay (Drive relay) 3 DriveRel (+)
22 X30 Relay (Main relay) 4 MainRel (-)
22 X30 Relay (Seat switch) 5 Seat (-)
22 X30 Relay (Drive relay) 6 DriveRel (-)
23 X40 Dig. Input (Throttle micro switch) 1 DIG_EIN_1A
23 X40 Dig. Input (Reserve 1) 2 DIG_EIN_2A , (TASKI AERO 3500µicro =>
Hand tool)
23 X40 Dig. Input (Reserve 2) 3 DIG_EIN_3A, (TASKI AERO 3500µicro =>
Pressure switch)
23 X40 Dig. Input (Reserve 3) 4 DIG_EIN_4A , (TASKI AERO 3500µicro =>
Temperature switch)
23 X40 n.c. 5 Not connected
Pos. Plug Description [plug] Pin Description [pin]
Table 2: Electronics connections
