MultiFlow  Configuration of the MultiFlow
9.3.3.3 Additive Pump (also called “dosage pump” or “Injection pump”)
No.
Name
Seal
K
Factory
Setting
Meaning
3.3.3
Additive Pump
3.3.3.1
Piston Capacity
Cal.
1
50 (m)
Additive volume per stroke in m .
3.3.3.2
Meter Factor
Cal.
1
1.0
Correction factor of additive pump.
IMPORTANT: Follow chapter 7.2 "Additive
Dispensing" / page 99 in setting this
parameter.
3.3.3.3
Pump Position
Cal.
1
1
Injection point of additive pump:
0: No function
1: Before measuring system
2: After measuring system (subject to W & M
inspection!)
3.3.3.4
Hose Volume
Cal.
1
50 (liter)
Volume of measuring system for wet-hose discharge
(measuring system + hose drum) in liters.
3.3.3.5
Ext. Prod. Sensor
M
2
0 (inactive)
Activates monitoring of the filling level on the external
storage tank.
IMPORTANT: The function is currently not
supported.
3.3.3.6
Pump Cycle Time
M
2
6000 (msec)
Maximum time for a pump cycle in msec.
3.3.3.7
Start Interval
Cal.
1
80 (msec)
Minimum dwell time of the piston in the initial position
in msec.
3.3.3.8
End Interval
Cal.
1
80 (msec)
Minimum dwell time of the piston in the end position
in msec.
Also consider the option of monitoring the load (chapter 6.9
"Monitoring the Load" / page 88) to prevent the additive pump from
running dry.
9.3.3.3.1 Notes on the pump position
 If an additive pump is not connected to the MultiFlow, parameter 3.3.3.3
must be set to 0. Activation of the additive operation in the product
registers (parameter 3.5.n.n.5.1) will in this case lead to a parameter
error.
 If dosing of the additive takes place in the product flow before the
measuring instrument, parameter 3.3.3.3 must be set to 1. In this case
the measuring instrument records the volume of the product plus
additive. As a result the additive is not noted separately on the
documents (delivery receipt, invoice, trip report).
 In the event of dosing of the additive in the product flow after the
measuring instrument, parameter 3.3.3.3 must be set to 2. In this case
the measuring instrument only records the volume of the product without
additive, whilst the additive quantity is provided by the number of pump
strokes and the (calibrated) volume of one pump stroke. In this case
separate details of the additive (description, quantity, price per unit, total
price) are given in the documents.
