MultiFlow  Configuration of the MultiFlow
The ability to dose the additives after the measuring instrument depends
on the software version.
§ Depending on the relevant regulations in the respective country it is
possible that technical calibration approval may be required for the
additive pump in the case of dosing after the measuring instrument.
9.3.3.3.2 Information regarding hose volume
 The hose volume of the measurement system includes the metering
equipment and the hose reel; it can be set using parameter 3.3.3.4. The
specification of the volume enables correct additive injection to the
product. In this manner the point in time for injection of the additive can
be selected such that even before the discharge is complete the additive
has been completely pumped out of the system so that none remains in
the hose or in the measurement system. You can find further details on
this topic in chapter 7.2 "Additive Dispensing" / page 99.
9.3.4 Form Description
No.
Name
Seal
K
Factory
setting
Meaning
3.4
Form description
3.4.1
Spacing
M
3
1 (characters)
Entry of spacing for the printout in mm or in
characters. Characters is the standard.
3.4.2
Columns Offset
M
3
0
Number of columns before the printout in mm or in
characters. Characters is standard.
3.4.3
Lines Offset
M
3
0
Number of lines before the printout in mm or in
characters. Characters is standard.
3.4.4
ReceiptLayout
M
2
-
Delivery receipt definition, form dialogue.
3.4.5
Print Form
M
Test printout of the delivery receipt.
3.4.6
Form Elements List
M
Printout of defined elements for describing the
delivery receipt.
See also chapter 10 "Form Description" / page 195.
9.3.5 Product Definition
No.
Name
Seal
K
Factory
Setting
Meaning
3.5
Product Definition
3.5.1
Product Page 1
Product registers 1.1 - 1.0
3.5.2
Product Page 2
Product registers 2.1 - 2.0
3.5.3
Product Page 3
Product registers 3.1 - 3.0
