MultiFlow  Configuration of the MultiFlow
• Extended parameter protection
If this parameter is activated, all sensor interface settings are under seal
protection and can only be changed when the W&M seal is broken. If the
parameter is deactivated, the parameters are protected only by the
master password.
All parameters for the configuration of the sensor-interface are
protected by the master password when the “Extended parameter
protection” is deactivated.
9.13.3 Configuration of the sensors
 The configuration of all the sensors takes place in the same way and is
stored under parameter 3.1.6.9.7. There is a predefined selection of
different sensor positions. As described, this relates either to individual
sensors (e.g. “Cabinet door right”) or to whole sensor groups (e.g. “Dome
cover”). The size of these sensor groups is defined using the
“Compartment number” parameter (3.1.6.9.3).
No.
Name
Seal
K
Factory
Setting
Meaning
3.1.6.9.7
Sensors
3.1.6.9.7.1
Dome cover
S/M
3.1.6.9.7.1.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.1.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.1.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.2
API coupling
S/M
3.1.6.9.7.2.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.2.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.2.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.2.4
Delay time
M
2
0s
Delay time for detecting a status change during
delivery
3.1.6.9.7.3
Foot valve
S/M
3.1.6.9.7.3.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.3.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.3.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
