MultiFlow  Configuration of the MultiFlow
No.
Name
Seal
K
Factory
Setting
Meaning
3.1.6.9.7.4
In-line valve
S/M
3.1.6.9.7.4.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.4.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.4.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.5
Cabinet door left
S/M
3.1.6.9.7.5.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.5.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.5.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.6
Cabinet door right
S/M
3.1.6.9.7.6.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.6.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.6.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.7
Handbrake
S/M
3.1.6.9.7.7.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.7.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.7.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.8
Ext. parameter
protection
S/M
2
0 (no)
Activates extended parameter protection. When
active, sensor interface parameters can be changed
only when the electronic seal is broken.
• Start sensor group
Group sensors and individual sensors are supported. In the case of
sensor groups, only the input number of the first sensor of each group is
specified. E.g. if a compartment number of “3” is specified, up to 3 dome
cover sensors are supported. A “Start sensor pos.” of “1” thus means that
the sensors connected to the sensor-inputs 1..3 are treated as dome
cover sensors. However individual sensors such as handbrake or cabinet
door sensors are allocated only one input each.
