MultiFlow  Configuration of the MultiFlow
DIP switch
Function
1
Node Number
2
Node Number
3
No function
4
No function
• Node Number
DIP 1
DIP 2
Node Number
OFF
OFF
16
ON
OFF
17
OFF
ON
18
ON
ON
19
9.14.2.2 MultiFlow
The basic parameters for configuration of the IO module are compiled
under the menu item 3.1.6.0.
No.
Name
Seal
K
Factory
setting
Meaning
3.1.6.0
IO interface
3.1.6.0.1
Use IO
M
2
0 (no)
Activation of the optional IO expansion
3.1.6.0.2
IO node
M
2
0
Node number of the IO expansion, if the latter has
been activated.
3.1.6.0.3
Transmission delay
M
2
50ms
Interface-end telegram delay on CAN bus. (0 ..
250ms)
3.1.6.0.4
Outputs
M
2
Configuration of the individual outputs
• Use IO
This parameter is used to activate the IO interface support. If this
parameter is set to '0' there is no IO interface control.
• IO node
This relates to the CAN bus node numbers via which the IO interface can
be addressed.
• Transmission delay
Adjustable transmission delay of the IO interface when transferring
several CAN telegrams. You should always consult the manufacturer
before changing this parameter.
All parameters for the configuration of the IO module which are not
used for the additional hose path specification are protected by the
master password.
